Kasco Decorative Fountain 8400JF 2 HP 240v 5 Interchangeable Patterns - Free Shipping

Kasco Decorative Fountain 8400JF 2 HP 240v | Kasco Floating Decorative Fountains

Kasco Decorative Fountain 8400JF 2 HP 240v
5 Interchangeable Patterns - Free Shipping

Write a Review

Starts at: $5,721.00

Shipping: Free

Brand: Kasco

SKU:8400JF050

Need accessories for this item?

View Accessories

Product Accessories

Part #:

Price Varies

Part #: LR375100

$1,072.80

Part #: LR375150

$1,140.30

Part #: LR375200

$1,208.70

Part #: LED3C11

Price Varies

Part #: KAS3400HA050

$1,124.00

Part #: KAS820107

$368.50

Part #: 431335K

$150.00

Part #: KAS110225

$125.00

Part #: 3400APumpReplace

$739.00

Part #: 223001

$371.00

Part #: U2.3J000

Was $3,744.00 Sale $2,999.00

Part #: disconnect

$179.00

Part #: KAHB

$16.11

Part #: LED3125x150

$652.50

Part #: LED3125x200

$703.80

Part #: LED3125x50

$572.99

Part #: LED6125x100

$1,404.45

Part #: LED6125x150

$1,529.10

Part #: LED6125x200

$703.80

Part #: LED6125x50

$1,339.00

Part #: LED8012W

$400.50

Part #: LR275

$828.01

Kasco has redesigned the J Series fountains for increased performance and improved pattern definition, all while maintaining the same cost of operation as current models.

These new models feature increased water flow for crisp and larger laminar displays, no increase in power (amp) usage, and new Balsam 3-tier pattern. Installation and assembly is now easier than ever with fewer parts required, 1-piece float, twist and lock nozzles, easier maintenance and snap-on light clips for installation of optional lighting (purchased separately).

Redesigned units are available in both 60Hz and 50Hz (1-5HP) options.

Kasco J Series fountains are the perfect focal point in any pond or lake. From the 30 ft. high attention-demanding Redwood pattern to the elegant Balsam 3-tier pattern, each nozzle offers its own visual appeal. Designed with both beauty and function in mind, these fountains can improve overall water quality by increasing oxygen transfer. All J Series Fountains come with multiple nozzles included in the price and can be paired with an optional light kit.

Package Includes

  • Motor unit
  • Float
  • Bottom screen
  • Interchangeable nozzles
  • Control panel with GFI protection
  • Mooring lines
  • Power cord
  • 50Hz units include a motor unit, 15m mooring lines, multiple nozzles and power cord

Fountain Nozzle Patterns:

BalsamLindenSpruce
BalsamLindenSpruceRedwood Birch

Manufacturer's Product Flyer

FEATURES AND BENEFITS OF THE 8400JF

Product update 2021:

Kasco's 2 hp J Series fountains now feature a 1 piece tapered float. This new float provides easier installation and improved appearance in the water. Their new light clip brackets that come with their light kits snap right onto this new float.

Premium Nozzles (sold separately) were also updated and improved along with the addition of the new Mighty Oak premium pattern.

The 8400JF, single phase unit is supplied with a state-of-the-art GFCB protected control panel, model C-85. The panel includes a 240 volt control panel with timer, GFCB protection, 120V GFI protected outlet for lights, and photocell for light operation. Kasco recommends a licensed electrician to install the C-85 control panel and the 8400JF if you plan to hard-wire the unit into the C-85 control panel.

Multiple Patterns in One Unit: Custom-configure the unit to the exact project needs and your personal tastes.

Efficient / Low Power Use: Highest efficiency design for low power consumption versus competing units. Reduces operating costs over the entire life of the unit. 10 running amps on a 240V, single phase circuit and 7.5 amps on 208/240V, 3 phase circuit for low operating costs.

Clog Resistant: Unique water-deflecting nozzle design gives you the most clog-resistant model on the market. Successful shallow water operation in as little as 20"

Rugged Motor: Environmentally friendly design with a hard-face internal mechanical seal and external lip seal for protection against leaks. Seals are silicone carbide for long life. Long-life top and bottom ball bearings. Flood oil lubricated for excellent heat dissipation.

Corrosion Resistant: Superior dependability in salt-water or other corrosive environments. All external metal motor, float, and hardware components are of stainless steel composition and protected by a sacrificial zinc anode.

Low Maintenance: Clean the motor housing once or twice per year and replacing the sacrificial zinc anode when visibly corroded.

Fully Tested: ETL listed to stringent UL and CSA Safety Standards.

Ships Easily: Via UPS in 3 or 4 boxes (add 1 box for lights)

Dependable: Backed by a three-year warranty

Choice of Cord Lengths: SJTOW or SOOW underwater rated power cord length options of 50', 100', 150', 200', 250', 300', & 400' (500' special order) Includes three 50' braided nylon mooring ropes.


Made in the U.S.A.

  Kasco Fountain Sizing Chart

 >10'

2400VFX

3400VFX

4400VFX

4400VFX

8400JF

8400JF

3.1JF

5.1JF

2HP Per Acre

 8-10'

1400JF

2400VFX

3400VFX

4400VFX

8400JF

8400JF

3.1JF

5.1JF

2 HP Per Acre

 5-8'

1400JF

2400VFX

3400VFX

4400VFX

8400JF

8400JF

3.1JF

5.1JF

 2 HP Per Acre

<5'

 1400JF

 2400VFX

3400VFX

3400VFX

4400VFX

 8400JF

3.1JF

 5.1JF

 2 HP Per Acre



<.25

0.25

0.5

0.75

1.25

1.5

2.5

>2.5

Total Surface of Acres of Ponds



1400JF



2400 VFX



3400VFX, 3400HVFX, 3400JF, or 3400HJF



4400VFX or 4400HVFX



8400JF



3.1JF



5.1JF

*The above recommendations are general idea for proper aeration in round, oval or square shaped ponds. Narrow or spread out bodies of water may be better served with multiple small units rather than one large unit.

*Irregular shaped ponds will require more HP per acer for proper aeration.

*Pond shape, Biological Oxygen Demand, and geographic area may affect sizing.

*A single surface acre is 43,560 Square feet or roughly 120' x 360'

Products Available In Varying Cord Lengths:

*Please contact ThePondOutlet.com for special pricing if cord length of more than 200 ft. is necessary

PondMeister Note:

For Aeration Sizing purposes, as a rough Rule-of-Thumb,  Kasco uses 1 HP for every Surface Acre of water.

One Surface Area of water is 43,560 square feet.

For example, if your pond is 100' x 100' you have 10,000 square feet of Surface Area. This would require a 1/4 HP Kasco Fountain

View the PDF for complete operating instructions.

View PDF Info Sheet
